Bosch Expert SDS MAX
Drilling deep into concrete or breaking out masonry? Bosch Expert SDS Max bits fit SDS Max hammers for those heavier jobs.
Choose Bosch Expert SDS Max drill bits for anchor holes and service routes, or chisels for breaking out. Check diameter, working length and hammer compatibility before buying. Shop the range to match the attachment to your job.
What Jobs Are Bosch Expert SDS Max Bits Best At?
- Drill deep fixing holes in concrete for structural brackets and baseplates, using the diameter and embedment depth specified for the anchor.
- Open service routes through concrete and masonry with a drill bit whose working length clears the wall thickness.
- Break out damaged concrete around repairs with a compatible SDS Max chisel and a hammer set to chiselling mode.
- Remove masonry during refurbishment with a pointed or flat chisel selected for the area being opened up.
Choosing the Right Bosch Expert SDS Max
Start with your hammer's tool holder, then match the bit to the hole or breakout work. SDS Max is not interchangeable with SDS Plus.
1. Drilling or Breaking Out
For fixing holes and service penetrations, choose from Bosch Expert SDS MAX Drill Bits. For breakout work, check Bosch SDS MAX Chisel Bits and select a profile suited to the material and removal area.
2. Diameter and Working Length
Buy the diameter specified by the fixing manufacturer, not the nearest size already in the van. Check working length separately from overall length; the shank does not count towards usable drilling depth.
3. Hammer Capacity and Material
Keep within your hammer's recommended drilling range and check the bit's stated material suitability. If you encounter reinforcement, stop and confirm whether it can be drilled; a suitable carbide head is not permission to cut structural steel.
4. Single Bits or a Set
If you repeatedly install one anchor size, buy that diameter rather than a mixed set. Consider a Bosch Expert SDS Max set only when its listed sizes and lengths cover your regular work.
Who Uses Bosch Expert SDS Max?
Groundworkers and steelwork installers use Bosch Expert SDS Max drill bits for deeper concrete fixings where smaller hammers would struggle. Mechanical installers use them for service penetrations, while refurbishment teams use compatible chisels to break out masonry. For other shank types and attachments, check Bosch Expert SDS Bits and Attachments before ordering.
The Basics: Understanding SDS Max Attachments
SDS Max describes the shank and tool-holder system. It determines which hammer accepts the attachment, not just how large a hole it makes.
1. A Sliding Shank Transfers Hammer Blows
The holder locks the attachment in place while allowing lengthwise movement for hammering. SDS Max shanks are larger than SDS Plus shanks, so the two do not fit the same holder.
2. The Attachment Determines the Mode
Drill bits use rotation and hammering to form holes. Chisels use hammer action without rotation. Your machine must support the required mode; an SDS Max breaker without rotation cannot drill holes.
Accessories for SDS Max Drilling and Breakout Work
Sort dust control and shank care before starting repeated concrete work.
1. Compatible Dust Collection Attachments
Concrete drilling creates hazardous dust. Check Bosch Drill Dust Collecting Attachments for compatibility with your bit diameter and setup, and connect to suitable extraction. Follow the task's dust-control assessment, including RPE where required.
2. SDS Shank Grease
Use the lubricant specified by your hammer manufacturer to reduce shank and holder wear. Clean the shank first and apply only the recommended amount; excess grease traps grit.
3. Anchor Hole Cleaning Equipment
Correctly sized brushes and an approved blow-out or vacuum system remove loose drilling dust before fixing. Follow the anchor instructions rather than assuming extraction at the hole mouth leaves it ready for installation.
Choose the Right Bosch Expert SDS Max for the Job
Match the attachment to the finished hole or the material you need to remove.
| Your Job | Attachment Type | Key Features |
|---|---|---|
| Concrete anchor installation | SDS Max drill bit | Specified hole diameter and sufficient working length |
| Deep service penetration | Long SDS Max drill bit | Working length beyond wall thickness and diameter within hammer capacity |
| Starting a localised breakout | Pointed SDS Max chisel | Concentrated contact for breaking hard material |
| Removing masonry in sections | Flat SDS Max chisel | Cutting width suited to the removal area and hammer |
Common Buying and Usage Mistakes
- Buying SDS Max for an SDS Plus hammer leaves you with an attachment that will not fit. Check the tool-holder specification, not just the Bosch name.
- Ordering by overall length can leave the hole short. Use the stated working length when checking drilling depth.
- Forcing the hammer slows progress and adds strain. Apply the pressure recommended for the tool and clear drilling debris as instructed.
- Using a chisel as a lever risks bending or breaking it. Break material into manageable sections instead of prising against the shank.
- Drilling without checking for services or reinforcement risks serious damage. Survey the area and follow the approved drilling plan before starting.
SDS Max vs SDS Plus vs Standard Chuck Bits
SDS Max
Choose this system for larger concrete drilling and heavier chiselling with a compatible hammer. The machines and attachments are generally heavier, so they are not the first choice for repeated small fixing holes.
SDS Plus
Usually the more manageable choice for routine plugs, brackets and smaller masonry holes. It uses a different shank and cannot accept Bosch Expert SDS Max bits.
Standard Chuck Masonry Bits
Straight-shank masonry bits suit compatible conventional hammer drills for lighter work. A normal three-jaw chuck does not accept SDS Max attachments or provide the same hammering mechanism.
Maintenance and Care
Clean Before Refitting
Remove grit from the shank before inserting it into the holder. Disconnect the tool from its power source before changing attachments or cleaning the holder.
Inspect the Head and Shank
Check for cracked carbide, damaged cutting edges and distorted shanks. Replace damaged bits; do not keep forcing one that drills oversize or no longer runs straight.
Let Hot Attachments Cool
Bits and chisels can become hot during sustained work. Allow safe cooling before handling or storage, and do not quench hot carbide heads in water.
Store Dry and Protected
Keep attachments dry in a case or rack rather than loose under other tools. Follow Bosch's instructions on whether a particular chisel can be resharpened; do not grind carbide drill heads freehand.
Why Shop for Bosch Expert SDS Max at ITS?
ITS stocks the Bosch Expert SDS Max range across drilling diameters, working lengths and breakout attachments, held in our own warehouse and ready for next-day delivery on in-stock lines. Check individual availability before ordering. If you also need a hammer, compare Bosch BiTurbo SDS Drills and confirm the selected model has an SDS Max holder.
Bosch Expert SDS Max FAQs
What is SDS max used for?
SDS Max is used for heavier concrete and masonry drilling, plus chiselling with compatible hammers. Typical jobs include larger anchor holes, service penetrations and breaking out concrete. Choose the attachment and operating mode for the task.
What is the difference between SDS plus and SDS max?
SDS Plus uses a nominal 10 mm shank, while SDS Max uses an 18 mm shank with a different locking arrangement. SDS Max generally serves heavier drilling and breaking work. The attachments are not directly interchangeable.
Can you use SDS max in a normal drill?
No. Bosch SDS Max attachments need a compatible SDS Max holder. They do not fit a normal three-jaw chuck or an SDS Plus holder. Do not modify the shank to make it fit.
Are Bosch sds max any good?
Bosch offers SDS Max attachments for demanding concrete and masonry work, but suitability depends on the exact bit, material and hammer. Check the cutting-head specification, working length and material rating. Even a suitable bit will wear quickly if forced, run in the wrong mode or used beyond its stated application.
Where are Bosch tools made?
Bosch manufactures tools and accessories in several countries. The Bosch brand alone does not establish where a particular SDS Max attachment was made. Check the product or packaging marking for the exact item if country of origin matters to your purchase.
Will these drill through reinforcement without damaging the bit?
Check the exact bit's specification for reinforced-concrete suitability; do not assume every SDS Max bit has the same capability. Reinforcement can still cause wear or binding. Stop when unexpected steel is encountered and obtain approval before drilling through it.
