Leica L2P5 Lino Cross Line Laser & Plumb Bob

Leica L2P5 Lino Cross Line Laser & Plumb Bob

(529179)

£229.99

EX VAT

(£275.99 INC VAT)

Adding to Basket… The item has been added

Leica L2P5 Lino Cross Line Laser & Plumb Bob

LEIL2P5 (529179)
(No reviews yet) Write a Review
In Stock
Delivery Information

Free Next Day Delivery Service

£229.99

EX VAT

(£275.99 INC VAT)

In Stock
  • promo-Freebie promotion
    Free Gift

  • promo-multibuy promotion
    Promotion

  • promo-category-based promotion
    Promotion

  • promo-brand-based promotion
    Promotion

  • promo-seasonal promotion
    Promotion

  • promo-flash promotion
    Promotion

Adding to Basket… The item has been added

Description

  • Product Code:LEIL2P5
  • Model Number: L2P5
  • Brand: Leica
  • Barcode: 7640110692639

Leica Lino L2P5 is the all in one layout and alignment tool.

The Leica Lino L2P5 combines all the advantages of the Lino dot and line lasers. It has four points and two lines which are exactly at right angles to one another.

With the Leica Lino L2P5 you are well equipped for any alignment or levelling task! Self-levelling, Exact 90° angle, Large glass lens, Modern, ergonomic housing, Very easy to use.

Very easy to see laser lines - The proven Leica optics and large emergence aperture of the laser project particularly long lines, an advantage warmly welcomed by users across  the full Lino range.

Transferring measured points - Turn the rotatable adapter to transfer reference points in no time at all across the room from one wall to another. Leave your spirit level and string line in your toolbox!

Horizontal and vertical aligning - Spirit levels & string lines are a thing of the past, now the Leica Lino L2P5 is the convenient way to transfer reference points from one wall to another or to ensure that wall and floor tile joints precisely meet one another.

Expanded range of applications - The adapter supplied with the Leica Lino L2P5 positions the instrument quickly and with absolute precision. You can set up the adapter over edges and profiles, attach it to circular columns or fix it to steel or iron pipes with the integrated magnets, maximum versatility.

Range: Up to 15m depending on lighting conditions
Range with detector: > 30m
Levelling accuracy @ 5m: ± 1.5mm
Self-levelling range: 4° ± 0.5°
Accuracy of plumb point @ 5m: ± 1.5mm
Accuracy of horizontal line @ 5m: ± 1.5mm
Vertical accuracy @ 3m line length: ± 0.75mm
Number of laser points: 4
Number of laser lines: 2
Beam direction: vertical, horizontal, up, down, right, left
Laser type: 635nm, laser class II
Batteries type: AA 4 × 1.5V
Protection class splash water/dust proof: IP54
Operating temperature: -10°C to 40°C
Storage temperature: -25°C to 70°C
Dimensions (H×D×W):  117.8 × 130.7 × 75.4mm
Weight without batteries: 370g
Tripod thread: ¼”



Specification

Dimensions 117.8mm x 130.7mm x 75.4mm
Batteries 4 x AA Batteries
Case Includes Carry Case
Run Time (approx) 14 Hours
Accuracy Range +/- 0.3mm/m
Self Levelling Range +/- 4°
Number of Lines Generated 2
Lines Axis Horizontal
Lines Axis Vertical
Lines Axis Various
Internal/External Suitable for Internal Use and External Use (With Detector)
Working Range 15m
Line Colour Red Beam
Indoor Visibility Range 15m
Exterior Visibility Range 30m (with detector)
Self Levelling Yes
Operating Temperature Range -10°C - 40°C
Protection Class IP54
Tripod Mount Thread 1/4
Detector Compatible Yes
Laser Class 635Nm Class II
Laser Type Crossline
Number of Dots Generated 4

Warranty Information

Leica Geosystems offers lifetime warranty coverage for the entire usage time of the product. Free of charge repair or replacement for all products that suffer defects as a result of faults in materials or manufacturing, for the entire life of the product.

For more information please see here:https://leica-geosystems.com/services-and-support/product-services/protect-by-leica-geosystems
